Product and Model Name
Product:Cylindrical Lithium Battery
Model Name:INR26650D
Ratings:
Capacity:4300mAh
Discharge:0.2C (860mA)
Nominal Voltage:3.70V
AC Impedance Resistance:≤15.0mΩ
Discharge Cut-off Voltage:2.50V
Charge Voltage:4.20V
Max. Charge Voltage:4.23V
Charge Time:4h Charge: 2100mA
Standard charge current:840mA
Max. Charge Current:2150mA
Max. discharge current:40000mA
Weight: 97g
Operating temperature:Charge: 0~+45℃
Discharge:-10~+60℃
Cycle Life :
30min rest period after 500mA charge,520mA discharge to a cut-off voltage of 3.0V, 30min rest period, the test shall be terminated when Discharging Capacity ≤80% C5 of Initial Capacity in three consecutive cycles. Standard charge and discharge at 25±2℃.
